Configuration
Product information
Choose a flat keyboard model for food service or a raised keyboard model for retail environments.
• Two-line alpha-numeric display shows each item as it is entered.
• Multi-Language Support: English, Spanish or French
• Connects to popular POS peripherals.
• Operator Display The easy-to-read, blue backlight, two-line by 16-character LCD operator screen identi- fi es each item as it is entered.
• Rear Display The 9-digit LED customer display allows consumers to monitor prices as items are entered and view the sale total.
• Quality Cash Drawer Features a 5 bill, 5 coin insert with adjustable coin dividers, two media slots and a standard security lock and key
• Secure SD Port SD Card Utilities include program Save/Load, report capture, fi rmware updates and graphics uploading.
Specifications
| Printer Type: | Direct Thermal, Drop-and-Print |
| Printer Stations: | Single Station; Receipt Printer |
| Printer Speed: | 22 Lines per Second |
| Paper Roll: | 2-1/4" (58mm) |
|
Displays- Operator: |
2-Line x 16 Character Alpha-Numeric Backlit LCD 9-Digit LED |
| Keyboard Capacity- Raised: |
150 Keys / 100 Programmable |
| Serial Ports: - Standard: Optional: |
COM1 & COM2 (D-Sub-9M) COM3 & COM4 (RJ45) |
| Cash Drawer Ports: | One RJ11 (24V) Port (Supports Open/Close) |
| SD Port: | Standard |
| Card Reader: | Optional Integrated Dual Track MCR |
| Standard Cash Drawer: | 5 Bill, 5 Coin with Drawer Lock and Two Media Slots |
| Carton Dimensions: | 22"L x 20" W x 15"H |
| Shipping Weight: | 30 lbs. |
| Power Requirements: | 120 AC ± 10%, 50/60 Hz |
| Power Consumption: | Approx. 25 Watts |
| Operating Temperature: | 32° ~ 104°F (0° ~ 40°C) |
| Humidity Range: | 30% to 80% RH (Non-Condensing) |
| Memory Protection: | Full Charge for 24 Hours will Protect Memory for 90 Days |
| In the Carton: | Starter Paper Roll / Key Set / User Manual / Power Switch Cover / Cable Router Clip / Paper Take-Up Spool (ER-940/945 Only) |
